Swan Q4B Hi-end Tweeter
$ 76.00
Postage : $0.00
Speaker Driver Dome tweeter
Stock: 0


Features:

Using 28mm German soft dome sound film, special damping layer treatment, the frequency response is broad and straight, and the sound performance is more transparent and clear. High-performance ferrite dual magnetic circuit design, linear uniform magnetic field, harmonic distortion can be effectively reduced. Lower distortion and better prevention of dynamic compression, improved resonant cavity design, high-impedance sound-absorbing materials. Professional liquid magnetic cooling technology, high temperature resistant aluminum alloy frame and copper clad aluminum wire voice coil, with greater power tolerance. To protect the precious treble diaphragm, a protective net is added to the panel to prevent the diaphragm from being deformed and damaged by external forces. Adhering to HiVi' s consistent Hi-end concept, the sound is more natural and smooth, and analytical performance are more layered, and the details are rich without unpleasant characteristics.


Swan Q4B Parameter
Parameters Mark Value Unit
Basic application parameters
Rated impedance Z 6 Ω
Resonant frequency Fs 700 Hz
Rated power Pnom 15 W
Maximum power Pmax 30 W
Sensitivity (2.83V/1m) E 90 dB
Weight W 0.76 kg
Voice coil
Voice coil diameter 28 mm
DC Resistance Re 5.1 Ω
Voice coil wire High temperature copper clad aluminum wire
Voice coil bobbin High temperature aluminum
Circuit
Magnetic circuit type Dual magnetic circuit
Magnet material High Performance Ferrite
Parameters
Recommended crossover point >2000 Hz


Swan Q4B Parameter
Parameters Mark Value Unit
Basic application parameters
Rated impedance Z 6 Ω
Resonant frequency Fs 700 Hz
Rated power Pnom 15 W
Maximum power Pmax 30 W
Sensitivity (2.83V/1m) E 90 dB
Weight W 0.76 kg
Voice coil
Voice coil diameter 28 mm
DC Resistance Re 5.1 Ω
Voice coil wire High temperature copper clad aluminum wire
Voice coil bobbin High temperature aluminum
Circuit
Magnetic circuit type Dual magnetic circuit
Magnet material High Performance Ferrite
Parameters
Recommended crossover point >2000 Hz
